No-Weld Fix for Small Steel Pipe Leaks
The Steel Pipe Repair Clamp (Banding Type) is a simple banding clamp for small steel pipe leaks. Steel pipes are common in industrial lines, fire systems, and heating networks. They are often installed above ground. A weld repair on an exposed steel pipe needs hot work and a shutdown. Our clamp uses mechanical locking only. No welding. No shutdown. It is a safe choice for steel pipe leak repairs.
The clamp is a single-piece open ring. The housing is QT450 ductile iron. The inside has an EPDM sealing pad. Slide it onto the pipe from the side and tighten the bolt. The sealing pad compresses against the steel surface. The clamp is small and does not add much bulk to the pipe. It does not block passageways or interfere with other equipment. You only need a standard wrench to install it.
We hold ISO 9001 certification. Our quality team hydro-tests every clamp at 2.4 MPa. We provide independent test reports on request. Our technical support team can help with product selection and installation.
Fixed a Factory Air Line Without Shutdown
An electronics factory had a galvanized steel compressed air line with a weld crack. The crack leaked air. The production line could not stop. Welding was not allowed in the workshop. The maintenance team used our Steel Pipe Repair Clamp (Banding Type). They installed it under pressure. The leak stopped. The clamp has been in service for over two years with no further leakage.
We offer a 10-year warranty. The epoxy coating resists corrosion on exposed pipe surfaces. The bolts have anti-rust treatment. We sell single pieces for urgent needs.
Technical Specifications
|
Parameter |
Specification |
|
Application |
Small steel pipe leak repairs (no welding) |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron |
|
Sealing Material |
EPDM rubber pad |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN15 – DN200 |
|
Warranty |
10 years |
