Fast Installation for Emergency Repairs
The Quick-Repair Pipe Clamp is designed for speed above all else. In emergency repair work, every minute counts. Our clamp uses a single-bolt locking system and pre-assembled components. You can install it in about five minutes. This makes it perfect for urgent repairs and temporary leak stopping.
The clamp has one quick-lock bolt instead of multiple bolts. The bolt has a large handle for hand-tightening. You can start the clamp by hand, then use a wrench for final tightening. The housing has a positioning catch at the opening. When you slide the clamp onto the pipe, the catch aligns the two ends automatically. You do not need to adjust the opening angle. The bolt comes pre-installed from the factory. There are no loose parts to lose at the job site.
We hold ISO 9001 and ISO 45001 certifications. Our quality team hydro-tests every clamp before shipping. Our after-sales team provides training and emergency use guidance. Prices are affordable for bulk stocking.
Used for Flood Season Preparedness
A city water company stocks our Quick-Repair Pipe Clamp before every flood season. Last year, a road collapse broke a DN150 water main. The repair team arrived on site and installed our clamp in six minutes. This gave them time to handle road backfill and traffic restoration. The company has now added the clamp to their standard emergency procedure manual.
We offer a 10-year warranty. The design is simple and reliable. The sealing pad stays fresh in storage. Sizes cover DN15 to DN200. We ship standard sizes same day.
Technical Parameters
|
Parameter |
Specification |
|
Application |
Emergency repairs, temporary leak stopping |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron (single-bolt) |
|
Sealing Material |
EPDM rubber pad |
|
Bolt Grade |
8.8 high-strength steel (with quick-turn handle) |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN15 – DN200 |
|
Installation Time |
~5 minutes |
|
Warranty |
10 years |
