Quick Fix for Socket End Leaks
The Socket Repair Clamp is a simpler version of our socket clamp. It is for quick fixes on socket end leaks. The socket end is where the pipe flares out. This area often leaks from ring failure or cracks. Our clamp gives you an economical way to fix these leaks.
The clamp has a single-piece open-ring design. The housing has a cavity for the socket bell. The sealing pad seals on both sides of the bell. Installation is fast. You slide the clamp onto the pipe, position it over the socket, and tighten the bolts. The dual seals stop the leak from both directions. This clamp is good for small and medium socket leaks.
We have 14 years of manufacturing experience. Our annual sales are 80 million RMB. We hold ISO 9001 certification and a health permit for drinking water. Every clamp is hydro-tested at 2.4 MPa before shipping.
Used County-Wide by a Water Company
A county water company has many socket joint leaks on their cast iron network. They equipped all repair teams with our Socket Repair Clamp. For DN100 to DN200 socket leaks, the average repair time dropped from over four hours to about 20 minutes. This gave them a huge efficiency boost.
We offer a 10-year warranty. The housing is QT450 ductile iron with epoxy coating. The EPDM sealing pad lasts over 10 years. Sizes cover DN50 to DN300.
Technical Parameters
|
Parameter |
Specification |
|
Application |
Socket end leak repairs |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron (with bell cavity) |
|
Sealing Material |
EPDM rubber (dual seal) |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN50 – DN300 |
|
Warranty |
10 years |
