Clamp-On Fix for Flanged Pipe Ends
The Flanged Repair Clamp is for pipes that already have a flange on one end. The flange face gets damaged. The sealing surface no longer holds pressure. Replacing the flange means cutting and re-welding. Our clamp bolts directly to the existing flange bolt holes. The other end wraps around the pipe. No cutting, no welding.
The clamp has two sections. One section is a flange plate. It has holes that match your flange bolt pattern. You bolt this section to your existing flange. The other section is a pipe wrap. It covers the pipe behind the flange. The two sections join together. This creates a sealed chamber around the damaged flange face. The original flange is still there. The clamp just adds a new sealing surface on top.
We have been making pipe repair products for 14 years. Our factory is in Nan'an City, Fujian Province. We hold ISO 9001 certification. We test every clamp at 2.4 MPa before shipping. Our technical team can work from your flange drawings. We custom-make each clamp to match your bolt pattern and pipe size. The housing is QT450 ductile iron with epoxy coating.
Installs Without Pipe Modification
A paper mill had a flanged pipe end with a damaged sealing face. The pipe carried process water. The flange could not be removed without stopping production. The mill used our Flanged Repair Clamp. They bolted it to the existing flange bolt holes. They tightened the pipe wrap section. The leak stopped. Production continued without any modification to the pipe.
The EPDM gasket works with many water types. The bolts are 8.8 grade. We offer a 10-year warranty. Provide us with your flange bolt circle diameter and pipe size. We will custom-make the clamp for you. Lead time is typically 15 to 20 days.
Technical Specifications
|
Parameter |
Specification |
|
Application |
Flanged pipe ends with damaged sealing faces |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron (flange plate + pipe wrap) |
|
Sealing Material |
EPDM rubber |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN50 – DN400 (custom based on flange specs) |
|
Custom Lead Time |
15 – 20 days |
|
Warranty |
10 years |
