Stops Leaks at T-Junctions
The Branch Tee Emergency Repair Clamp is made for leaks at tee branch connections. Tee joints are the most complex points in a water network. They connect the main pipe to a branch line. This creates stress concentration. Leaks at tees are harder to fix than straight pipe leaks. Our clamp is designed for this exact challenge.
The housing has a T-shape. It covers the main pipe and the branch pipe in one piece. The main section wraps around the main pipe. The branch section wraps around the branch pipe. The two sections are cast as one integrated housing. The gasket follows the T-shape continuously. It seals along the main pipe and around the branch connection. The clamp encloses the entire tee area. It creates a complete seal around the T-junction.
We have our own R&D team with many patents. We are experienced in making tee repair products. We can custom-make based on your tee dimensions. Tell us the main pipe size and branch pipe size. We hold ISO 9001 and ISO 14001 certifications. Our products have a health permit for drinking water.
Fixed a Factory Fire Line Leak
A chemical plant had a tee leak on their fire water line. The tee connected a DN200 main to a DN100 branch. The system could not be shut down. The plant used our Branch Tee Emergency Repair Clamp. The T-shape housing fit perfectly. The leak stopped on the first attempt. The plant now keeps our tee clamps in their emergency stock.
We offer a 10-year warranty. The housing is QT450 ductile iron with epoxy coating. The gasket is EPDM rubber. Provide your tee dimensions for a custom fit.
Technical Parameters
|
Parameter |
Specification |
|
Application |
Tee branch connection leaks |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron (T-shape integrated) |
|
Sealing Material |
EPDM rubber (continuous seal) |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Main Pipe Range |
DN50 – DN400 |
|
Branch Pipe Range |
DN50 – DN200 |
|
Warranty |
10 years |
