Fixes PE Pipe Fusion Joint Leaks
The Hot Melt Joint Repair Clamp is made for leaks at PE pipe hot melt fusion joints. PE pipes are joined by heat fusion. The joint area has a raised bead or ring of melted material. If the welding temperature or pressure is wrong, the joint may crack later. This clamp repairs the leak without cutting the pipe and without re-welding.
The housing is longer than standard clamps. It covers the entire fusion bead area. The bead is enclosed inside the housing cavity. The gasket has two main seal rings. One is on each side of the bead. The bead itself does not carry pressure. The water pressure is stopped by the gaskets outside the bead area. The housing has tapered guides at both ends. These help slide the clamp over the bead during installation. All edges that touch the PE pipe are rounded. This prevents scratches on the pipe surface.
We have our own R&D team with several patents. Our engineers can design the housing length based on your bead width and height. Each batch comes with material test reports and pressure test records. You can review these at any time.
Safe for Gas and Water PE Lines
A gas company in a northern city found a micro-leak on a PE gas pipe fusion joint. Gas lines cannot use welding or open flames for repairs. You also cannot shut off gas flow easily. The company used our Hot Melt Joint Repair Clamp. They installed it without welding and without stopping gas flow. A soap bubble test confirmed the seal was tight. This method is now their standard procedure for PE gas joint leaks.
Our EPDM gasket resists methane and ethane gases. It does not swell or degrade in contact with hydrocarbons. The epoxy coating also resists chemicals. This makes the clamp suitable for gas, chemical, and industrial pipelines. We offer a 10-year warranty on this product. The gasket is designed to be hydrocarbon-resistant for long service life.
Technical Parameters
|
Parameter |
Specification |
|
Application |
PE pipe hot melt fusion joint leaks |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron |
|
Sealing Material |
Hydrocarbon-resistant EPDM rubber |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN50 – DN400 (based on bead dimensions) |
|
Warranty |
10 years |
