Connect Pipes in Minutes
The Quick Pipe Connector is our fastest connection product. In repair and emergency work, every minute counts. This connector uses a single-bolt locking system. The installation takes only a few minutes. It is perfect for temporary water supply and emergency pipe bypass.
The housing has a fixed hinge on one side and a single quick-lock bolt on the other. To install, insert both pipe ends into the connector. Close the housing. Tighten the one bolt. The self-locking mechanism engages automatically. No extra steps are needed. The connector comes pre-assembled from the factory. The seals and bolts are already in place. Open the box and install it directly.
Our annual sales exceed 80 million RMB. We have a large inventory of standard sizes. Orders ship within 24 hours. Our after-sales team provides remote installation support. We ship across all of China.
Set a Speed Record
A water group in central China tested many connectors in a flood emergency drill. The Quick Pipe Connector had the fastest installation time. The average was four minutes. The group now stocks this connector at all their emergency response stations. They use it for burst main bypass and temporary water supply during floods.
We offer a 10-year warranty. The product has few moving parts. Reliability is very high. The EPDM gasket lasts for years in storage. The epoxy coating resists corrosion in outdoor conditions.
Technical Parameters
|
Parameter |
Specification |
|
Application |
Emergency repairs, temporary water supply |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron (hinged, single-bolt) |
|
Sealing Material |
EPDM rubber (pre-installed) |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN50 – DN300 |
|
Installation Time |
3 – 5 minutes |
|
Warranty |
10 years |
