Mechanical Connections for PE Pipes
The PE Pipe Universal Connector connects polyethylene pipes without heat fusion. PE pipes are common in rural water projects, city networks, and gas lines. Traditional PE connections use butt fusion or electrofusion. These need special equipment, power supply, and certified welders. The joint needs cooling time. Our connector uses mechanical locking and sealing. No power is needed. No welding equipment is needed. No special skills are needed.
The connector design accounts for PE pipe properties. PE pipes are flexible and have soft surfaces. Our housing is a full-wrap design. It surrounds the pipe end completely. This prevents the pipe from swelling under pressure. The gasket hardness is lower than standard. It seals well but does not damage the PE surface. The sealing contact area is wide. This spreads the sealing force and protects the pipe surface.
We have several patents for PE pipe connection products. Our technical team has deep field experience. We hold ISO 9001 and ISO 14001 certifications. Our products have a health permit for drinking water systems. We inspect every product for dimensions and pressure resistance before shipping.
Helped a Remote Mountain Village
A rural water project in a southwestern mountain area had no electricity. They needed to connect PE pipes without power tools. The construction team used our PE Pipe Universal Connector. They used only manual wrenches. The project used over 120 connectors. All pressure tests passed. The solution proved that PE pipes can be connected even without electricity.
We offer a 10-year warranty. Sizes cover DN50 to DN400. All ODs match national PE pipe standards. You can install this connector under pressure with water still flowing. It is a practical tool for daily PE network maintenance.
Specifications
|
Parameter |
Specification |
|
Application |
PE water pipe connections (no heat fusion needed) |
|
Working Pressure |
≤1.6 MPa |
|
Housing Material |
QT450 ductile iron (full-wrap design) |
|
Sealing Material |
Low-hardness EPDM rubber (does not damage PE) |
|
Bolt Grade |
8.8 high-strength steel |
|
Surface Treatment |
Epoxy powder coating |
|
Diameter Range |
DN50 – DN400 |
|
Installation |
No power, no heat fusion equipment, no welder needed |
|
Warranty |
10 years |
